Setting constant voltage output

Select “Const Volt”
Place the cursor in the first field of the second line by
pressing the select arrow keys (left and right arrows
under the display). Then press the adjust arrow keys
(pointing up and down) until “

Const Volt” displays in

the field.
As you scroll through the four options, a short beep
indicates each change.

Set the voltage value
Place the cursor under the digit in the V digit field that
you wish to change by pressing the select arrow keys.
Select the value of the digit by pressing the adjust arrow
keys. A short beep indicates that the change was regis-
tered. Repeat for each of the three active digits in this
field (1–200 V).

When the start/stop key is pressed to start the run, the
cursor will be in the V field to indicate that this value is
being held constant. This value can be edited without
switching to SET mode. To edit other parameters during
a run, press the set/read key.

Note: The maximum current
available at 200 V is 1000 mA
due to the relationship W = V·A.

•

p11

#1 Protocol 1
Const Volt 200 V
Timed Hrs
Step 1 10:00 hrs
