30
NO. NAME SYMBOL SPECIFICATION PART CODE Q'TY
1 BUZZER BZ1 BM-20K 3515600100 1
2 C ARRAY CA1 7P(6) 102 M 50V CN6XB-102M 1
3 CAPACITOR ELEC EC1 25V RS IMF CEXE1H109A 1
4 CAPACITOR ELEC EC2 25V RSS 1000uF DEZF1E102V 1
5 CONNECTOR WAFER CN1 YW396-02V 3519150520 1
6 CONNECTOR FILM CN2 FCZ254-11 441M367160 1
7 CONNECTOR WAFER CN3 YW396-05V 3519150510 1
8 DIODE RECTIFY D1~6, 9~12 1N4148 DZN4148--- 10
9 DIODE RECTIFY D12, 14 1N4004A DZN4004A-- 2
10 DIODE ZENER ZD1 UZ-5.1BSB DZUZ5R1BSB 1
11 DIODE ZENER ZD2 UZ-3.9BSB DZUZ3R9BSB 1
12 LED DISPLAY DP1 DDG-631H DDDG631H01 1
13 PCB MAIN M158 81.5X139.9 3514315410 1
14 R ARRAY RA1 7P(6) 1/8 100K J RA-87X104J 1
15 RESISTOR R1~R7 1/6W 330 5% RD-AZ331J- 7
16 RESISTOR R8,10,14,22 1/6W 1K 5% RD-AZ102J- 4
17 RESISTOR R9,23 1/6W 4.7K 5% RD-AZ472J- 2
18 RESISTOR R11,20,21 1/6W 100K 5% RD-AZ104J- 3
19 RESISTOR R12 1/6W 20K 5% RD-AZ203J- 1
20 RESISTOR R13 1/6W 200 5% RD-AZ201J- 1
21 RESISTOR R15~16 1/6W 10K 5% RD-AZ103J- 2
22 RESISTOR R17 1/6W 510 5% RD-AZ511J- 1
23 RESISTOR R18 1/6W 1M 5% RD-AZ105J- 1
24 RESISTOR R19 1/4W 51 5% RD-4Z510J- 1
25 REGULATOR VL1 MC7905C 1MC7905C-- 1
26 TRANSISTOR Q1~5, 9~11 KRA-102M TZRA102M-- 8
27 TRANSISTOR Q6 KTA-1266Y TZTA1266Y- 1
28 TRANS POWER LVT1 DMR-631P 5EPU035302 1
29 WIRE COPPER J1~3,5~8,10~12,17~21 1/0.52 TIN COATING 85801052GY 15
30 WIRE COPPER SJ3 1/0.52 TIN COATING 85801052GY 1
31 IC MICOM IC1 TMP47C440B-NG17 13GS862GH0 1
32 RESONATOR CERA CR1 KBR-4.0MSTF 5PKBR40MKS 1
33 SW RELAY RY1 G5G-1A DC12V 5SC0101121 1
34 SW RELAY RY2 OJ-SS-112LM 5SC0101404 1
35 CAPACITOR CERA C6 102 50V Z AXIAL CCZB1H102K 1
36 CAPACITOR CERA C1~5,C7 104 50V Z AXIAL CCZF1H104Z 6
3. P.C.B. LOCATION NO.
1) KOR-630A0A/1A
