Chipset
► North Bridge/ South Bridge
Press to go to its submenu.
North Bridge
Memory Information
► Total Memory
This item displays the current memory size. The size is depending on how many memory
modules are installed in your system before powering on.
► Memory Slot1/2/3/4
These items display the memory size installed on each slot.
► Memory Hole Remapping
This item is used to enable/disable memory remapping around memory hole.
Memory Information Memory Remap Enable/Disable
Total Memory 512 MB (DDR2 667)
Memory Slot1 512 MB
Memory Slot2 0 MB
Memory Slot3 0 MB
Memory Slot4 0 MB
Memory Hole Remapping [Enabled]
Memory Frequency [Auto]
Memory Timing By [BySPD]
IGD Memory [32MB]
DVMT Memory [256MB] →←: Select Screen
↑↓: Select Item
PCI Express X16 Port [Auto] Enter: Select
Initial Graphic Adapter [PEG/IGD] +/-: Change Opt.
VT-d [Disabled] F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save ESC: Exit
