Chapter 2 Installation Instructions

17

Expansion Slots

This motherboard includes three 32-bit master PCI slots,one PCI Express

x 1 slots,one PCI Express x 4 slots and one PCI Express x 16 slots.

PCI Slots

The expansion cards can be installed in the three PCI slots. PCI slots support

cards such as a LAN card, USB card, SCSI card and other cards that comply

with PCI specifications.

PCI Express x1 Slots

This motherboard has one PCI Express x1 slot that designed to accommodate

less bandwidth-intensive cards, such as a modem or LAN card.

PCI Express x4 Slots

This motherboard has one PCI Express x4 slot that designed to accommodate

modem ,network card. But actually the x4 slots only offering 500MB/sec.

PCI Express x16 Slots

This motherboard has one PCI Express x16 slots that reserved for graphics or

video cards. The difference in bandwidth between the x16, x4 and x1 slots is

notable to be sure, with the x16 slot pushing 4GB/sec (8GB/sec concurrent) of

bandwidth, the PCI Express x4slot offering 500MB/sec,and the PCI Express x1

slot offering 250MB/sec.

For the detailed PCI Express x16 graphics cards support list on this

motherboard, please visit the website:

http://www.foxconnchannel.com
