Chapter 1 Product Introduction
6
7. Optical S/PDIF Out Port
This port is used to connect an external audio output device via a Optical S/PDIF
cable.
8. Line in, Line out, Microphone, Rear, LEF/CEN, Side Jacks
When using an 8-channel sound source, connect the front speaker to the green
audio output; connect the rear sound speaker to the black audio output; con-
nect the center speaker/subwoofer to the orange audio output; connect the side
sound speaker to the grey audio output.
9. LAN Ports
This port allows connection to a Local Area Network (LAN) through a network
hub.
10. 1394a Port (optical)
This port is used to connect a 1394 device.
11. Parallel Port
The port is used to connect a parallel port device, such as a printer.
