OWNER’S MANUAL
PARTS LIST
CGP20B
CGP20LB
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed
under Replacement Parts on page 17 of this manual.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 098304-01 Screw, #10 x 3/8" 2
2 098742-03 Front Panel (CGP20B) 1
098742-19 Front Panel, Ivory (CGP20LB) 1
3 103476-01 Grill Guard 1
4 101108-01 Grill Guard Clip 2
5 104189-01 Bottom Glass Retainer 1
6 098260-09 Glass Panel 1
7 098303-02 Screw, #8 x 3/8" 2
8 M11084-26 Screw, #10 x 3/8" 6
9 104618-01BR Deflector Unit 1
10 098271-03 Ignitor Cable 1
11 098249-01 Nut, M5 2
12 103594-04 ODS/Pilot Assembly 1
12-1 098514-01 Thermocouple 1
12-2 106842-01 Ignitor Electrode 1
13 103446-01 Burner 1
14 099387-05 3/16" Pilot Tubing 1
15 103845-01 Injector 1
16 099066-01 Mounting Bracket 1
17 099415-06 Pressure Regulator 1
18 099553-01 Pilot Shield 1
19 103570-01 3/8" Outlet (Burner) Tubing 1
20 103572-01 3/8" Inlet Tubing 1
21 100068-01 Pressure Tap Fitting 1
22 100047-04 Control Valve 1
23 104617-07 Cabinet, Woodgrain (CGP20B) 1
104617-08 Cabinet, Ivory (CGP20LB Only) 1
24 097159-04 Piezo Ignitor 1
25 098276-01 1/8" NPT Plug 1
26 098354-01 Control Knob 1
27 098508-01 Valve Retainer Nut 1
PARTS AVAILABLE — NOT SHOWN
098306-02 Control Position Decal (CGP20B) 1
098306-03 Control Position Decal (CGP20LB) 1
103571-01 Operating Instructions Decal 1
100642-01 Assembly, Hardware 1
