Page 19
19
104412
OWNER’S MANUAL
PARTS LIST
RP30E
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed
under Replacement Parts on page 17 of this manual.
KEY
PART
NO.
NUMBER
DESCRIPTION
QTY.
1
098304-01
Screw, #10 x 3/8"
2
2
098345-01AC
Front Panel
1
3
103476-02
Grill Guard
1
4
101108-01
Clip, Grill Guard
2
5
104658-01
Heat Shield
1
6
M11084-26
Screw, #10 x 3/8"
6
7
104102-02
Deflector Unit
1
8
098271-03
Ignitor Cable
1
9
098249-01
Nut, M5
2
10
103594-04
ODS/Pilot, LP
1
10-1
098514-01
Thermocouple
1
10-2
106842-01
Ignitor Electrode
1
11
103447-01
Burner
1
12
099387-05
3/16" Pilot Tubing
1
13
103845-03
Injector
1
14
099066-01
Mounting Bracket
1
15
099415-06
Pressure Regulator
1
16
099553-01
Pilot Shield
1
17
103570-01
3/8" Outlet (Burner) Tubing
1
18
103572-01
3/8" Inlet Tubing
1
19
100068-01
Pressure Tap Fitting
1
20
100047-02
Control Valve
1
21
104617-09
Cabinet
1
22
097159-04
Piezo Ignitor
1
23
098303-02
Screw, #8 x 3/8"
2
24
098276-01
1/8" NPT Plug
1
25
098354-01
Control Knob
1
26
098508-01
Valve Retainer Nut
1
PARTS AVAILABLE — NOT SHOWN
098306-02
Control Position Decal
1
099261-02
Operating Instructions Decal
1
100642-01
Assembly, Hardware
1
