► Smart Power LED (Optional)
Smart Power LED is a feature built on your motherboard to indicate different states during
Power-On Self-Test (POST). The LED is located at the front panel, and it displays POST state
by different long-short blinking intervals. You can always leave this state enabled.
► Smart Boot Menu
When PC starts, it will ask you to press [Del] key to enter setup or press [Esc] key to enter
smart boot menu. If [Disabled] is selected, then pressing [Esc] has no function. This also
prevents user without password trying to get into your computer through smart boot menu.
► Current CPU Speed
This item displays the current CPU speed.
► Current FSB/HTT Speed
This item displays the current Front Side Bus speed.
► Current CPU Multiplier (Appears only when CPU supports)
This item displays the current CPU Ratio.
► Current DRAM Speed
This item displays the current DRAM speed, in dual channels.
Fox Intelligent Stepping
► CPU Clock
This option is used to adjust the CPU clock.
CMOS Setup Utility - Copyright (C) 1985-2006, American Megatrends, Inc.
Fox Intelligent Stepping
CPU Clock [200] Help Item
PCI Express Clock [100]
CPU Multiplier Adjust [Auto]
Spread Spectrum [Enabled]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[200]
System Status Power LED Status
Normal On
No CPU Fan Blinking once (blinking 0.5 sec., off 0.5 sec.)
No Display Blinking once (blinking 2 sec., off 2 sec.)
No Memory Blinking twice
Post Error Message Blinking thrice
