Appendix

Step2. Connect power extension cable to the graphics card power connector and
power supply connector.

Step 3. Install the SLI Bridge Board to the goldfingers on each graphics card. Make
sure that the connector is firmly in place.

Step 4. Connect the 4-pin ATX power cable to the Auxiliary power connector to secure
the system is stable.

Step 5. Power on your computer and boot into Operating System.

Step 6. Install the NVIDIA graphics card drivers and restart your computer.

Power Extension
cable
