39 107123
OWNER’S MANUAL
For more information, visit www.desatech.com
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 26 of this manual. PARTS LIST
Thermostatically-Controlled
Biltmore Split Oak Model
CCL3930NTA
KEY CCL3930NTA
NO. PART NUMBER DESCRIPTION QTY.
1 105923-02 Front Log (#1) 1
2 105924-02 Middle Log (#2) 1
3 105925-02 Back Log (#3) 1
4 105926-02 Left Back Crossover Log (#4) 1
5 105927-03 Left Top Crossover Log (#5) 1
6 105928-02 Right Bottom Crossover Log (#6) 1
7 105929-02 Right Top Crossover Log (#7) 1
8 102844-01 Lower Bracket 1
9 102966-01 Upper Bracket 1
10 098867-14 Gas Regulator 1
11 102981-01 Inlet Tube 1
12 102983-01 Outlet Burner Tube 1
13 099056-16 Burner Orifice Injector 1
14 102843-01 Burner Clip 1
15 102772-01 Burner 1
16 101329-20 Thermostat Gas Valve Assembly 1
17 102979-01 Thermostat Bracket 1
18 098544-01 Thermostat Clip 1
19 102445-01 Piezo Ignitor 1
20 099387-09 Pilot Tube 1
21 098271-07 Ignitor Cable 1
22 104285-01 ODS Pilot 1
23 M11084-38 Hex Screw, #8-18 x .38 15
24 098249-01 Nut, M5 2
25 099211-01 Hex Screw, 10-16 x 2.50 2
26 102775-07CK Painted Base Assembly 1
PARTS AVAILABLE — NOT SHOWN
100563-01 Warning Plate 1
101054-01 Lighting Instructions Plate 1
100565-01 Warning Plate Fastener 1
100639-01 Caution Decal 1
101137-02 Hardware Kit 1
107073-02 Information Video 1
GA6060 Lava Rock 1
102030-01 Auxiliary Thermostat
Mounting Clip
1
