31 107123
OWNER’S MANUAL
For more information, visit www.desatech.com
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 26 of this manual. PARTS LIST
Thermostatically-Controlled
Premium Aged Split Oak Models
KEY CGB3924NT CGB3930NT
NO. PART NUMBER PART NUMBER DESCRIPTION QTY.
1 104897-01 104897-02 Middle Log (#1) 1
2 104898-01 104898-02 Back Log (#2) 1
3 104899-01 104899-02 Crossover Log (#3) 1
4 104896-01 104896-02 Front Log (#4) 1
5 104900-01 104900-02 Log Piece (#5) 1
6 102844-01 102844-01 Lower Bracket 1
7 102966-01 102966-01 Upper Bracket 1
8 098867-14 098867-14 Gas Regulator 1
9 102981-01 102981-01 Inlet Tube 1
10 102983-01 102983-01 Outlet Burner Tube 1
11 099056-16 099056-16 Burner Orifice Injector 1
12 102843-01 102843-01 Burner Clip 1
13 102772-01 102772-01 Burner 1
14 101329-20 101329-20 Thermostat Gas Valve Assembly 1
15 102979-01 102979-01 Thermostat Bracket 1
16 098544-01 098544-01 Thermobulb Clip 1
17 102445-01 102445-01 Piezo Ignitor 1
18 099387-09 099387-09 Pilot Tube 1
19 098271-07 098271-07 Ignitor Cable 1
20 104285-01 104285-01 ODS Pilot 1
21 M11084-38 M11084-38 Hex Screw, #8-18 x .38 15
22 098249-01 098249-01 Nut, M5 2
23 099211-01 099211-01 Hex Screw, 10-16 x 2.50 2
24 102775-05CK 102775-07CK Painted Base Assembly 1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 Warning Plate 1
101054-01 101054-01 Lighting Instructions Plate 1
100565-01 100565-01 Warning Plate Fastener 1
100639-01 100639-01 Caution Decal 1
101137-02 101137-02 Hardware Kit 1
104310-02 104310-02 Information Video 1
GA6060 GA6060 Lava Rock 1
CGB3924NT
CGB3930NT
