QT19D328SC User’s Manual

25

Video Display

Single picture, built-in quad display

Video Standard

PAL system:

25 frames/second CCIR625 lines 50 fields

NTSC system:

30 frames/second CCIR625 lines 50 fields

System Resources

Real time recording resources, one or four channels can play backward at the same

time

;one or four channel monitoring, network real time monitoring

Audio

Audio Input

Two channels independent input

600Ω RCA

Audio Output

Two channels independent output

600Ω RCA

Basic Output Gain

1.0-2.2V

Distortion Plus Noise

≤-30dB

Recording Solutions

Volume and Image are Synchronized

Audio Compression

MPEG-1

LAYER2

System

Operating Language

English

Operating Interface

OSD (On Screen Display) menu

Password control

Password for users and administrators

Digital

Processing

and Storage

Image Compression

MPEG-4

Variable bit streams/ Constant bit streams

Image format

Built-in quad

:CIF format(352×288

pixels

Single picture

: HD1 format ( 704×576

pixels

Video code rate

6.25-350Kbyte/s

6.25-250Kbyte/s

Video volume taken in H.D.

22.5M-1260Mbyte/hour

22.5M-900Mbyte/hour

Resolution

Play backward 352×288 Pixels

,real time monitoring 704×576 pixels,VGA output

704×576 pixels

Video current standard

ISO14496

Audio current standard

ISO11172

Audio code rate

24Kbyte/s

Audio volume taken in H.D.

86.4Mbyte/hour

Internal Storage

One IDE hard drive

,up to 300GB

Image quality

8 adjustable levels

:1-8 with 1 highest quality

Data read and write method

Full duplex

Alarms

Motion Detection

192 detecting areas can be set, and 16 levels adjustable sensitivity
