10, 15, 20 ACCESS I and 10-40 Access M 39 Actuators Intrinsically Safe
WCAIM2028
Flow Control
Worcester Controls
PARTS LISTING
ITEM
QTY.
DESCRIPTION
ITEM
QTY.
DESCRIPTION
1
1
Actuator Body
12
2
Piston Set Screws (if any)
2A
1
Shaft (10-2039)
13
1
Conduit Plug – Not Shown on ACCESS I
2B
1
Shaft (25-4039)
14
Varies
Springs – See Table on page 11
3
2
Pistons
15A
2
End Cap O-Rings
4
2
Guide Rods
15B
6
Guide Rod O-Rings
5A
1
ACCESS I End Cap or ACCESS M Enclosure
15C
2
Piston O-Rings
5B
1
End Cap
15D
1
Top Shaft O-Ring
5C
8
End Cap Screws (Metric)
15E
1
Bottom Shaft O-Ring
5D
1
Cover “Z”
15F
1
Shaft Clip
5E
1
Caution Nameplate “Z”
15G
1
Top Pinion Bearing
5F
1
Cover “W”
15H
1
Bottom Pinion Bearing
5G
1
O-Ring – Cover
15J
1
Anti-Ejection Ring (Sizes 25–40)
5H
1
ACCESS M Endcap
16
1
Wiring Diagram – Not Shown
5J
1
Caution/Wiring Label “W”
17
1
Position Indicator
6A
4
Cap Bearing (Split-Ring Style)
18
2
Drive Screw
6B
2
Piston Bearing (Split-Ring Style)
19
2
Probes
7A
1
Control Block Assembly
20
2
O-Rings – Probe
7B
1
Air Connection Block (No Solenoid)
21
4
Washers – Probe (ACCESS I only)
7C
-
Not Used
22
2
Retaining Clips – Probe (4 for ACCESS M)
7D
4
Block Bolts
23
2
Spring – Probe (ACCESS I only)
8A
1
Solenoid Assembly
24
1
Terminal Strip
8B
2
Solenoid Exhaust Port Fittings
25
2
Mounting Screws – Terminal Strip
8C
1
Solenoid Exhaust Tubing
26A
1
Limit Switch Assembly – left
8D
1
Solenoid Adapter
26B
1
Limit Switch Assembly – right
8E
2
O-Rings
27
4
Mounting Screws – Limit Switch
9A
1
Gasket – Control Block (Double-Acting)
28
2
Switch Adjustment Screw
9B
1
Gasket – Control Block (Spring-Return)
29
2
Switch Adjustment Spring
9C
1
Gasket – Air Conn. Block (No Solenoid)
30
2
Terminal Strip Dividers
10
1
Thrust-bearing
31
1
Exhaust Port Plug (If No Solenoid)
11
1
Nameplate
To order proper parts, please specify the actuator size, model, and revision number. Use the standard nomenclature listed above.
The rebuilding kits include Items 15A through 15H, 6A and 6B, 10, and S.S. washers. Color of some replacement parts, such as bearings, may
vary from the parts removed.
ADDITIONAL PARTS LISTING (For ACCESS M only)
ITEM
QTY.
DESCRIPTION
ITEM
QTY.
DESCRIPTION
32
2
Drive Screws
38
2
Flat Washer – Switch
33
1
Bracket-Switch
39
2
Upper Mounting Screw – Enclosure (1
1
/
8
" Long)
34
3
Mounting Screws – Switch Bracket
39A
2
Lower Mounting Screw – Enclosure (1" Long)
35
2
Retaining Ring – Switch
40
1
Gasket
36
2
Button – Switch
41
1
Nameplate
37
2
Spring – Switch
42
4
Threaded Tamper Proof Plug
