41-22 Flowserve Corporation, Valtek Control Products, Tel. USA 801 489 8611
Kit 7 - Remote Mount Pressure Sensor Hardware Kit
Part No. 10061025
Item No. Description Quantity
3 Swagelok nut 4
4 Swagelok ferrules 4
15 Temperature extended fitting 2
19 Adapter fitting 2
NOTE: Kit will service two remote-mount pressure
sensors. See Table XII for tubing. (Wet-leg tubing wall
thickness must be 0.065-inch).
Kit 8 - Remote Mount Pressure Sensor Hardware Kit
with Purge and Isolation Valves
Part No. 10061026
Item No. Description Quantity
3 Swagelok nut 4
4 Swagelok ferrules 4
15 Temperature extended fitting 2
16 Purge valve 2
17 Isolation valve 2
19 Adapter fitting 2
NOTE: Kit will service two remote-mount pressure
sensors. See Table XII for tubing. (Wet-leg tubing wall
thickness must be 0.065-inch).
Kit 9 - Explosion Proof Union Fitting
Part No. 10007238
Item No. Description Quantity
14 Explosion proof union 1
Kit 10 - Pressure Sensor Electrical Cable
Replacement Kit
Part No. 10061117
Item No. Description Quantity
1 Electrical connector cable 1
22 Four-pin connector 1
23 Wire crimp terminal 4
NOTE: Kit will service two pressure sensors.
Kit 11 - Pressure Sensor Electrical Extension Cable
Part No.
10054518
Description Quantity
Electrical connector extension cable 1
Kit 12 - Pressure Sensor Calibration Kit
Part No. 10061118
Description Quantity
Pressure sensor calibration fixture 1
Electrical connector extension cable 2
O-ring seal, Viton 2
NOTE: Two sensors can be calibrated simultaneously
with this kit.
Kit 13 - DP Cell Manifold Replacement
Part No. 10203723
Description Quantity
Valve manifold 1
Temperature Probe Kits
See temperature sensor configurations drawing for
item numbers.
Kit 14 - Standard Temperature Probe Replacement,
Div II Configuration
Part No. 10055955
Item No. Description Quantity
2 Standard temperature probe 1
Kit 15 - Standard Temperature Probe Replacement,
Div I Configuration
Part No. 10070891
Item No. Description Quantity
2 Standard temperature probe 1
6 Adapter fitting 1
7 Adapter fitting 1
Kit 16 - Through Hole Temperature Probe
Replacement
Part No. 10065272
Item No. Description Quantity
2 Through hole temperature 1
probe
