Flowserve 2000 Series Digital Positioner User Manual
Page 18
42-18
Flowserve Corporation, Valtek Control Products, Tel. USA 801 489 8611
Actuator
Shaft Size
Air To
Mounting
Size
Kit
25
0.625
Open
10059458
25
0.625
Close
10059458
25
0.75
Open
10059459
25
0.75
Close
10059459
25
0.875
Open
10059460
25
0.875
Close
10059460
50
0.625
Open
10059461
50
0.625
Close
10059462
50
0.75
Open
10059463
50
0.75
Close
10059471
50
0.875
Open
10059472
50
0.875
Close
10059473
50
1.125
Open
10059476
50
1.125
Close
10059477
100
0.875
Open
10059474
100
0.875
Close
10059475
100
1.125
Open
10059478
100
1.125
Close
10059479
100
1.5
Open
10059480
100
1.5
Close
10059481
100
1 0.75
Open
10059482
100
1 0.75
Close
10059483
200
1.125
Open
10094606
200
1.125
Close
10094607
200
1.5
Open
10094608
200
1.5
Close
10094609
200
1 0.75
Open
10094610
200
1 0.75
Close
10094611
Table V: Valdisk Rotary Actuator
Mounting Kits
Mounting kit includes bracket, linkage assembly,
follower arm, and all necessary nuts, bolts and
washers.
Table VII: Valdisk 150 Rotary Actuator
Mounting Kits
Actuator
Shaft Size
Air To
Mounting
Size
Kit
25
0.625
Open
10059458
25
0.625
Close
10059458
25
0.875
Open
10059460
25
0.875
Close
10059460
50
0.625
Open
10059461
50
0.625
Close
10059462
50
0.875
Open
10059472
50
0.875
Close
10059473
50
1.0625
Open
10059484
50
1.0625
Close
10059486
50
1.34375
Open
10059489
50
1.34375
Close
10059490
100
0.875
Open
10059474
100
0.875
Close
10059475
100
1.0625
Open
10059487
100
1.0625
Close
10059488
100
1.34375
Open
10059492
100
1.34375
Close
10059495
100
1.375
Open
10059496
100
1.375
Close
10059504
100
1.5
Open
10059480
100
1.5
Close
10059481
100
1 0.75
Open
10059482
100
1 0.75
Close
10059483
200
1.0625
Open
10094612
200
1.0625
Close
10094613
200
1.34375
Open
10094614
200
1.34375
Close
10094615
200
1.375
Open
10094616
200
1.375
Close
10094617
200
1.5
Open
10094608
200
1.5
Close
10094609
200
1 0.75
Open
10094610
200
1 0.75
Close
10094611
Mounting kit includes bracket, linkage assembly,
follower arm, and all necessary nuts, bolts and
washers.
Table VIII: Completed Assemblies
Description
Number
StarPac II assembly
10007028
Logix 2000 assembly
10053635
Table VI: StarPac Accessories
Description
Number
Converter, RS232/RS485, 110/220 VAC 10055963
StarPac Analog Interface (8 Channel),
24 VDC
10069207
Power supply, DIN rail mounted,
110 VAC to 24 VDC
10079519
