Flowserve AKH3 Atomac Lined Ball Valve IOM - Manual (Page 12)

AKH3 - atomac ball valve - reduced port
Ahaus GmbH
von-Braun-Straße 19a
D-48683 Ahaus
Postfach 1162 D-48661 Ahaus
Telefon: +49(0) 2561-686-100
Fax: +49(0) 2561-686-200
Register: 3
Page: 13
Date: 05.1996
Revision: 08.2010
Technical Manual
Material specification - AKH3 with
actuator mounting
Item-No. 010 “threaded pin” is used with sizes DN 20, 25, 40 and 1“, 1½“ only.
No. Designation Pieces Material Material-No. DIN ASTM / AISI
010 threaded pin 1 stainless steel 1.4301 DIN EN 10088-3 A 193 B8
020 actuator bracket 1 steel (yellow chromated) 1.0037 DIN EN 10025-2 A 283-B
030 serrated lock washer 4 stainless steel 1.4301 DIN EN 10088-3 AISI 304
040 hexagon bolt 4 stainless steel 1.4301 DIN EN 10088-3 A 193 B8
050 adaptedr 1 stainless steel 1.4304 DIN EN 10088-3 AISI 430F
