Globe Valves FCD ADENIM0011-00
3
Table of Contents (continued)
6.0
DISASSEMBLY Page
6.1 Actuator Removal.....................................................17
6.1.1 Handwheel.................................................18
6.1.2 Gear...........................................................19
6.1.3 Electric Motor.............................................20
6.2 Flanged Bonnet Valves ............................................20
6.2.1 Packing ....................................................20
6.2.2 Yoke ....................................................21
6.2.3 Bonnet ....................................................22
6.2.4 Disc and Stem ...........................................23
6.3 Pressure Seal Bonnet Valves ..................................24
6.3.1 Yoke ....................................................24
6.3.2 Bonnet ....................................................25
6.3.3 Disc and Stem ...........................................29
7.0
ASSEMBLY
7.1 Flanged Bonnet Valves ............................................30
7.1.1 Disc and Stem............................................30
7.1.2 Bonnet........................................................30
7.1.3 Yoke...........................................................31
7.2 Pressure Seal Bonnet Valves ..................................31
7.2.1 Disc and Stem............................................31
7.2.2 Bonnet........................................................31
7.2.3 Yoke...........................................................32
7.3 Actuators..................................................................32
7.3.1 Manual Actuators.......................................32
7.3.2 Air Cylinder and Motor ...............................32
