Flowserve Cast Globe Valves - Manual (Page 2)

Globe Valves FCD ADENIM0011-00
2
Table of Contents
1.0
VALVE DESCRIPTION Page
1.1 Recommended Uses..................................................6
1.2 Principles of Operation...............................................6
1.3 Design Features ......................................................7
1.3.1 Bodies ......................................................7
1.3.1 Bonnet Seals ...............................................8
1.3.2 Disc Assembly and Seats ............................9
1.3.3 Actuation......................................................9
2.0
CARE OF VALVE PRIOR TO INSTALLATION
2.1 Receiving Inspection................................................10
2.2 Handling ................................................................10
2.3 Storage ................................................................10
3.0
INSTALLATION INSTRUCTIONS
3.1 Rigging ...................................................................11
3.2 Cleaning ...................................................................11
3.3 Installing Valve In Line .............................................11
4.0
OPERATING THE VALVE
4.1 Hand Actuated .......................................................12
4.2 Motor Actuated .......................................................12
4.3 Throttling .......................................................12
4.4 Isolating .......................................................12
4.5 Operating Tips ........................................................13
5.0
VALVE MAINTENANCE
5.1 Inspection.................................................................14
5.2 Lubrication ...............................................................14
5.3 Cleaning ...................................................................14
5.4 Packing ...................................................................15
5.5 Bolting Torque Values..............................................16
5.6 Refinishing Sealing Surfaces ...................................17
