Assembly Instructions
Numbers in parentheses note the illustration numbers as located on
pages 5 and 6 of this brochure. Refer to this illustration to assist in
assembling your Hypregun-Plus 5Q.
Your Hypregun-Plus 5Q is shipped disassembled. The contents of
the shipping container include:
Part Illustration
Qty. Name Number
2 Wheel 79
2 Axle 75
2 Retaining ring 77
2 Setscrew 81
1 Handle 71
2 Capscrew 31
4 Steel washer 32
2 Lock nut 90
2 Spacer 61
2 Pipe plug 88
2 Kick stand 74
2 Washer 83
1 Hex nut 85
1 Hex nut 86
1 Capscrew 87
1 Capscrew 84
1 Spring 76
1 Washer 82
1 10 foot hose assy.
1 Gun sub-assembly
Tools
Tools required for assembly of the Nordstrom
Hypregun-Plus 5Q:
■
Adjustable wrench
■
3/16" Allen wrench
■
1/2" socket (two required)
■
socket wrench (two required)
■
socket extension
■
pliers
Assembly
The following instructions reference the front and back of the
Hypregun-Plus 5Q. The integral handle of the yoke (12) is
considered the front of the gun.
Handle Assembly
1. Locate the two drilled holes in the top of the yoke (12).
2. Remove from the parts bag two 5/16" stainless steel hex head
capscrews (31), two 5/16" stainless steel washers (32), two
5/16" stainless steel lock nuts (90), two spacers (61), and two
pipe plugs (88).
3. Position the horseshoe shaped handle (71) with the bend
upward and extending toward the back of the yoke (side
opposite the yoke handle).
4. Install the handle spacers (61) into the open ends of
the handle.
5. Secure the handle using the parts as described in Step 2 and
as illustrated on page 5. The steel washers are to be positioned
between the head of the capscrew and the handle and the lock
nut and the yoke.
6. Tighten using the socket wrenches and socket extension.
7. Insert the pipe plugs (88) into the opens ends of the handle.
Wheel Assembly
1. Locate two wheels (79), two axles (75), two retaining rings
(77), and two setscrews (81).
2. Lay the Hypregun-Plus 5Q on its back.
3. Using pliers, install the retaining ring (77) into the groove on
the end of the axle (75).
4. Place the axle through the hub of the wheel (79) making sure
the axle is inserted from the side of the wheel with the air
valve stem.
5. Insert the axle into the axle hole on the side of the base (18).
6. Insert the setscrew into the drilled and tapped hole in the
bottom of the base and tighten securely using a 3/16" hex
head Allen wrench.
