10
A = Model no
D20 Digital compact positioner, General purpose, LED status
B = Approval, Certificate
D General purpose version
I Intrinsically safe version ATEX
C = Connections Air, Electrical
M 1/4" NPT air, M20 x 1,5 electrical x 2
N 1/4" NPT air, 1/2" NPT electrical x 2
D = Housing/Surface treatment
U Aluminium/Powder epoxy, black
E = Function
S Single acting
D Double acting, incl gauges (2) Stainless/Brass
F = Mounting options / Spindle
09 Double D type, adaptor spindle
12 Flowtop, D-style+ nut, direct mounting, Kit 30144 include
23 VDI/VDE 3845 rotary, Mounting kit not included
39 IEC 534-6, Flat D type, nut incl. Mounting kit not included
40 VDI/VDE 3847 Linear, Flat D, Mounting kit 30145 included
G = Cover and Indicator
PVA PMV,Black cover, Arrow indicator
PVB PMV, Black cover, No indicator
PVD PMV, Black cover, Dome indicator
H = Temperature/seals
Z Standard -20°C to 85°C (-4°F to 185°F)
Q Low temp -40°C to 85°C (-38°F to 185°F)
I = Input signal/Protocol
4 4-20 mA / none
5 4-20 mA, / HART
J = Feedback option, 4-20 mA transmitter, switches
X No feedback option
T 4-20 mA transmitter only
S Limit switches Mechanical SPDT + 4-20mA
N Namur V3 type sensor, P+F NJ2-V3-N + 4-20mA
P Limit switches Proximity SPDT + 4-20mA
4 Slot type Namur sensor, P+F SJ2-S1N + 4-20mA
5 Slot type Namur sensor, P+F SJ2-SN + 4-20mA
6 Slot type Namur sensor, P+F SJ2-N + 4-20mA
K = Options, Add in electronics
0 Standard diagnostics
L = Accessories
X No accessories
M Gauge block 1/8" G (2 x gauges included)
N Gauge block 1/8" NPT (2 x gauges included)
Example: A A A B C D - E F F G G G - H I J K L
4.4 D20 Model Code
