Available Spare Part Kits For Logix 1400 Digital Positioner
Kit 1 - Driver Module Assembly
Part No. 10070864
Item No. Description Quantity
55 Driver module 1
52 Spool valve block 1
53 Screw, spool valve to housing 2
54 O-ring, spool valve 3
57 Screw, driver to housing 2
56 Nylon washer 2
Kit 2 - Soft Goods Kit
Part No. 10070866
Item No. Description Quantity
3 O-ring, main housing cover 1
15 O-ring, driver module cover 1
32 O-ring, customer interface cover 1
40 O-ring, customer interface
terminal block 1
46 O-ring, sensor to housing 3
54 O-ring, spool valve 3
62 O-ring, feedback shaft 1
5 O-ring, main cover window 1
19 O-ring, coalescing filter housing
to interface plate seal 1
12 O-ring, spool valve cover 1
22 Gasket, interface plate 1
35 Gasket, manifold 1
17 Internal coalescing filter 1
28 Hydrophobic filter 1
Kit 3 - Standard Collector Board Assembly
Part No. 10116059
Item No. Description Quantity
44 Collector board 1
45 Standoff 1
46 O-ring, sensor to housing 3
49 Adapter, pressure sensor seal 1
48 Screw 2
47 Collector board stiffener 1
50 Screw, collector board to
housing 2
51 Screw, collector board to
standoff 1
Kit 4 - Advanced Collector Board Assembly
Part No. 10116058
Item No. Description Quantity
44 Collector board 1
45 Standoff 1
46 O-ring, sensor to housing 3
47 Collector board stiffener 1
50 Screw, collector board to
housing 2
51 Screw, collector board to
standoff 1
Kit 5 - Customer Interface Assembly
Part No. 10116061
Item No. Description Quantity
38 Field termination board 1
39 Screw, field termination board 3
40 O-ring, field termination board 1
41 Grounding screw 1
Kit 6 - Main PCB Assembly
Part No. 10116434
Item No. Description Quantity
42 Main PCB assembly 1
43 Screw, main PCB assembly 3
67 Washers, Nylon 3
Kit 7 - Regulator
Part No. 10070875
Item No. Description Quantity
16 Regulator and captive O-rings 1
Kit 8 - Orifice Assembly
Part No. 10070876
Item No. Description Quantity
24 Orifice barbed fitting and gasket 1
25 Flexible tubing 1
26 Hex barbed fitting with captive
O-ring 1
27 Hex plug with captive O-ring 1
Kit 9 - Stem Position Sensor
Part No. 10061643
Item No. Description Quantity
58 Stem position sensor 1
