48-14 Flowserve Corporation, Valtek Control Products, Tel. USA 801 489 8611
Shaft Kit, NAMUR End Connection – Part No. 10118753
Item No. Description Quantity
52 Cam Shaft 1
112 Retaining Ring 2
128 Jam Nut 1
Feedback Spring Kit – Part No. 10094524
Item No. Description Quantity
47 Feedback spring assembly (Includes 1
item Nos. 103, 104)
48 Pivot block 1
49 Adjustment knob 1
50 Lock knob 1
Manufacturer-Specific Spare Parts Kits
Sereg Cam Kit – Part No. 10116036
Item No. Description Quantity
53 Direct Acting Cam 1
125 Reverse Acting Cam 1
126 Cam Cover Clip 1
127 Screw 1
130 Cam Spring 1
131 Screw 1
132 Sticker, Cam 1
Cover Kit, Lens, White, Sereg – Part No. 10118691
Item No. Description Quantity
2 Cover 1
3 Screw 4
117 O-ring 1
119 Sereg Lens 1
116 Indicator 1
118 O-ring 1
Cover Kit, Lens, Black, Accord – Part No. 10118697
Item No. Description Quantity
2 Cover 1
3 Screw 4
117 O-ring 1
119 Accord Lens 1
116 Indicator 1
118 O-ring 1
Cover Kit, Lens, White, Valtek – Part No. 10118690
Item No. Description Quantity
2 Cover 1
3 Screw 4
117 O-ring 1
119 Valtek Lens 1
116 Indicator 1
118 O-ring 1
Cover Kit, Lens, Black, Automax – Part No. 10118698
Item No. Description Quantity
2 Cover 1
3 Screw 4
117 O-ring 1
119 Dome 1
116 Indicator 1
118 O-ring 1
Electronic Spare Parts Kits
WARNING: Internal electronic kits cannot be used in applica-
tions requiring explosion-proof components.
As an alternative, the explosion-proof UltraSwitch position
indicator may be mounted to the top of the positioner. Consult
your local Flowserve representative for ordering information.
Transmitter Kit, 4-20mA Output, Double D Shaft End
Connection – Part No. 10118423
Item No. Description Quantity
52 Cam Shaft 1
112 Retaining Ring 2
128 Jam Nut 1
54 Lock Washer 1
55 Nut 1
130 Electronics Kit (Includes shaft gear, 1
circuit board and mounting screws)
