Exacq exacqVision Edge/Illustra Quick Start Guide - Manual (Page 4)

www.e x acq.com Page 4 of 5
2/25/2015
9. Ensure the Total Size for SD Card is greater than zero, which means the camera is communicating with the SD
card.
10. From the Setup menu, select Applications.
11. Complete the following steps on the Applications page, as shown in the following illustration:
a. Select Browse and then locate the .enc or .tar file downloaded in step 6.
b. Select Upload. It may take up to five minutes for the package to load and install.
c. After successfully installing exacqVision Edge, exacqVision Server is displayed in the Available Applications
list.
12. In the local exacqVision Client, add the remote Edge server on the Add System page using the default
exacqVision Server username (admin) and password (admin256). This allows the local client on your computer
to communicate with the Edge
server on the camera. When complete, the server’s status is displayed as
Connected.
b a
c
