Dacor MWDH27 - Manual (Page 7)

5
Installation Specifications
A
Warming Drawer
Warming Drawer
B
3/4" Min.*
(19 mm)
D
5/8" Min.*
(16 mm)
120 Vac
electrical
receptacle
36" Typ.
(914 mm)
C
C
Warming Drawer
Cooktop
1 1/2" (38 mm)
Typical counter top
3/4” Min.*
(19 mm)
120 Vac
electrical
receptacle
A
36" Typ.
(914 mm)
B
C
27"/30"/36"
Dacor
single oven
Warming Drawer
Warming Drawer
Toe Kick
D
C
D
C
120 Vac
Elect.
120 Vac
Elect.
A
5/8" Min.*
(16 mm)
Cutouts Dimensions
Cutout Depth: 24” Min. (610 mm)
Model
“A” Cutout
Width
“B” Min.
Width to
Adjacent
Doors/
Drawers
“C” Cutout
Height
“D” Min.
Vertical Gap
Between
Cutouts
IWD24 22 1/4”
(565 mm)
24 1/4”*
(616 mm)
9 1/8”
(232 mm)
1 1/16”*
(27 mm)
EWD24
EWD27
25 1/4”
(641 mm)
27 1/4”*
(692 mm)
IWD27
MWDH27
MWDV27
MRWD27
PWD27
EWD30
28 1/4”
(717 mm)
30 1/4”*
(768 mm)
IWD30
MWDH30
MWDV30
MRWD30
PWD30
EWD36
34 1/4”
(870 mm)
36 1/4”
(921 mm)
* Bare minimum spacing shown to allow for ventilation and avoid scrapping. On
IWD series models, additional space may be required if an oversized drawer front
is used. Use the drawer face dimensions for the corresponding EWD series model
on page 4 for reference.
