HIGH LEVEL HARNESSES
NNOOTTEE!! Do not connect the high level input connections to power, signal, or
chassis ground as damage to the head-unit outputs may result. The
high-level inputs are designed to work with either grounded or BTL
speaker level outputs (found on most head units).
NNOOTTEE!! Also, to preclude the use of the High Level Harness, a speaker level to
RCA adapter is available (Directed p/n 55020) to convert any regular
or high-powered speaker output to a preamp level, high impedance
signal to drive the amplifier.
33000022,, 66000022,, 55000011,, 88000011 HHiigghh LLeevveell CCoonnnneeccttiioonnss
66000044 HHiigghh LLeevveell CCoonnnneeccttiioonnss
Wire Color Input Connection
WHITE + Left Front channel
WHITE/BLACK - Left Front channel
BLACK Ground
GREEN/BLACK - Right Rear channel
GREEN + Right Rear channel
GRAY + Right Front channel
GRAY/BLACK - Right Front channel
VIOLET/BLACK - Left Rear channel
VIOLET + Left Rear channel
Wire Color Input Connection
WHITE/BLACK - Left channel
BLACK Ground
WHITE + Left channel
GRAY/BLACK - Right channel
GRAY + Right channel
