51
2
Hardware Installation
LAN LED Connector
The LAN LED connector is used to connect to the LAN LEDs that are usually lo-
cated at the front panel of the chassis.
1 7
2
3VDU 3VDU 3VDU 3VDU
LAN2_ACTIVE
8
LAN1_ACTIVE LAN4_ACTIVE LAN3_ACTIVE
