24

2

Hardware Installation

COM 2 RS232/Power Select

J6

6

2

5

3

1

4

1-3, 2-4 On:

RS232 standard

(default)

6

2

5

3

1

4

3-5 (+12V),

4-6 (+5V) On:

RS232 with power

6

2 4

5

3

1

J6

DCD-

TD

RD

D

TR

-

GND

1 2 3 4 5

R

T

S-

RI

-

DSR

-

CT

S-

6 7 8 9

+5V

TD

RD

D

TR

-

GND

1 2 3 4 5

R

T

S-

+12V

DSR

-

CT

S-

6 7 8 9

COM 2
