BIOS Setup
F75387 Module Board H/W Monitor
Enables CPU SmartFan
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
=== Module Board H/W Monitor ===
Current CPU Temperature
Vcore
VGFX
+1.5(V)
+3.3(V)
Current CPU FAN Speed
CPU Smart Fan Mode Setting
Manual Value
Advanced
: +52.0 C
: +1.104 V
: +0.448 V
: +1.520 V
: +3.328
: N/A
[Manual Mode]
255
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
ESC: Exit
CPU Smart Fan Mode Setting
The options are Manual Mode and PWM mode.
Manual Value
Allows you to manually enter the CPU fan’s speed.
