3. Note the key on the socket. The key ensures the
module can be plugged into the socket in only one
direction.
SODIMM socket
1. Locate the DIMM socket on the system board.
Installing an SODIMM
2. Push the ejector tabs which are at the ends of the
socket at the side.
Ejector tab
Ejector tab
