CHARGER
BATTERY
PACK
RELEASE TAB
RELEASE TAB
BATTERY
PACK
COLLET NUT
SWITCH
Functional Description & Specifications
Disconnect battery pack from tool or place the switch in the locked or off position before
making any assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
Cordless Rotary Tool
Rotary Tools
Model number
750
754
770
Voltage rating
4.8 V
4.8 V
7.2 V
No load speed
no 6,500-13,000/min
no 5,000-10,000/min
no 10,000-20,000/min
Collet Capacities
1/32”, 1/16”, 3/32”, 1/8”
Chargers
Model number
756-01
758-01
Voltage rating
120 V 60 Hz
Amperage rating
200 mA
200 mA
Charge time
3 Hr.
3 Hr.
