To configure the IP parameters via the terminal cable:
Step Procedure
1 Using a terminal emulator on a PC such as HyperTerminal™ or TeraTerm™, set up the
communication port as follows:
• 38,400 BAUD
• 8 Data Bits
• 1 Stop Bit
• No Parity
• No Flow Control
2 Press the key on the PC – the login prompt should be displayed.
3 The default user is comtech and the default password is comtech. After logging in, the CMR-
6000’s menu should be displayed.
4 Press “N” for Network Menu.
5 Press “I” for the IP Address, Enter the IP Address and press .
6 Press “M” for the Subnet Mask. Enter the Subnet Mask and press .
7 Press “G” for the Default Gateway IP Address. Enter the Default Gateway Address and press
.
8 Press “S” to save the parameters.
9 Press “Y” to confirm the saving of parameters.
10 Press “X” to exit to the main menu.
To configure the IP parameters via the front panel:
Step Procedure
1 Use the keypad to navigate the Vacuum Fluorescent Display (VFD) menu display
2 Select the Config menu option
3 Select the Ethernet menu option
4 Select the IP Address option and enter the IP address (in dotted decimal format ) and
subnet mask (in CIDR format)
5 Select Gateway and enter the IP address of the default gateway
6 Select Link and enter the appropriate speed/duplex setting. Auto is the default and
recommended configuration of the LAN interface
After completing the final step in either of these procedures, the unit has been configured for full IP
operation. The tuner settings may also be configured via the front panel, although additional
configuration and management is best performed using the web interface (refer to Chapter 4, Device
Management via User Interfaces, in the installation and operation manual).
Once fully configured, the coaxial connection to the Low Noise Block (LNB) may be safely attached to
the L-Band input port. Read Section 2.5, Connect External Cables, in the installation and operation
manual for more information about the LNB connection.
Download Product Documentation
Full product documentation, including the installation and operation manual, is available for
download from
www.comtechefdata.com/ProductDigicast.asp .
