50
Connection T Connection T o The Ports (continued) o The Ports (continued)
AUDIO IN 1
AUDIO IN2 RGB RGB OUT
REMOTE CONTROL
AUDIO OUT CR/PR CB/PB
CONTROL
R - AUDIO IN - L VIDEO IN S-VIDEO IN
Y
R/CR/PR G/Y B/CB/PB H V
BNC
F
D-Sub 9 pin
plug
CONTROL port
F CONTROL
1 2 3 4 5
6 7 8 9
Computer side
D-Sub 9 pin
jack
5 4 3 2 1
9 8 7 6
1
2
3
4
5
6
7
8
9
RD
-
TD
-
-
GND
-
CTS
RTS
1
2
3
4
5
6
7
8
9 CD
RD
TD
DTR
GND
DSR
RTS
DTS
RI
D-Sub 9 pin
jack
5 4 3 2 1
9 8 7 6
D-Sub 9 pin
plug
RS-232C port
1 2 3 4 5
6 7 8 9
memo About the details of RS-232C communication, please refer to the
following page.
