49
Connection T Connection T o The Ports (continued) o The Ports (continued)
Mini Din 4 pin jack
1 2
3 4
I VIDEO IN
• RCA jack
• System: NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43, PAL60
• 1.0 ± 0.1 Vp-p at 75
Ω terminator
K
COMPONENT (C
R
/P
R
, C
B
/P
B
, Y)
• RCA jack x3
• System: 525i (480i), 525p (480p), 625i (575i), 720p, 1080i/1035i
• Y signal: 1.0 ± 0.1 Vp-p at 75
Ω terminated with composite sync.
• C
B
/P
B
signal: 0.7 ± 0.1 Vp-p at 75
Ω terminated
• C
R
/P
R
signal: 0.7 ± 0.1 Vp-p at 75
Ω terminated
K AUDIO IN 1
AUDIO IN2 RGB RGB OUT
REMOTE CONTROL
AUDIO OUT CR/PR CB/PB
CONTROL
R - AUDIO IN - L VIDEO IN S-VIDEO IN
Y
R/CR/PR G/Y B/CB/PB H V
BNC
L
J
I
L
REMOTE CONTROL
• 3.5 dia. Stereo mini jack
• To be connected with the remote control that came with the projector.
J
S-VIDEO
Pin Signal
1
Color signal: 0.286 Vp-p (NTSC, burst), 75
Ω terminator
Color signal: 0.300 Vp-p (PAL/SECAM, burst), 75 Ω terminator
2 Brightness signal: 1.0 Vp-p, 75 Ω terminator
3 Ground
4 Ground
