www.desatech.com 111076-01F 6
kEY
NO.
PART NO. DESCRIPTION QTY.
1 111066-03 Control Panel Decal • 1
111066-01 Control Panel Decal • 1
111067-0 Control Circuit Harness • • 1
3 11105-01 4" Black Wire Harness • • 1
4 11105-0 4" White Wire Harness • • 1
5 11105-03 4" Green Wire Harness • • 1
6 111058-01 Flame Control • •
7 1107-01 Panel Control • • 1
8 10834-01 ON/OFF Switch • 1
10834-01 ON/OFF Switch •
11304-01 Hole Plug • 1
10 103651-01 Lock.Nut • •
11 103650-01 Control Knob • •
1 103646-01 Power Wire Harness • • 1
13 015-13 Terminal Block • •
14 1110 #8 - 32 x 3/8" Phillips Screw • • 5
PARTS AvAILABLE - NOT SHOWN
11475-01 4".Wire.Tie • • 14
111066-01 Control Panel Decal • 1
111066-03 Control Panel Decal • 1
1146-01 Lamp Bulb (Red) • • 1
1146-0 Lamp Bulb (Yellow) • • 1
1146-03 Lamp Bulb (Orange) • • 1
** Not a field replaceable part.
PARTS
CONTROL PANEL FOR MODELS E32L, E32LB, E32LH, E32LBH, E36L,
E36LB, E36LH AND E36LBH
This list contains replaceable parts used in your fireplace. When ordering parts, follow the
instructions listed under Replacement Parts on page 23 of this manual.
1
2
5
3
4
10
6
7
8
8/9
11
12
14
14
14
13
13
E32/36L(B)(H) E32/36L(B)
