PARTS LIST
BURNER ASSEMBLY FOR MODELS v42N-A, vv42NSB(1), vv42NHB(1), v42P-A, v42PSB(1),
vv42PHB(1) AND CHDv24NR-B
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts
on page 28 of this manual.
kEY
NO. PART NO.
DESCRIPtION
qtY.
1
108373-01 Burner Assembly Base
1
108330-01 Pan Burner Assembly
1
3
11165
Screw #10 x 5/8" MD TR BLK
1
4
108376-01 Tube Burner
1
5
104506-4 Pan Burner Orifice (Natural Gas #46)
1
104506-0 Pan Burner Orifice (Propane/LP)
1
6
108084-0 Pilot Assembly (Natural Gas)
1
108084-03 Pilot Assembly (Propane/LP)
1
7
1110
Screw #8-3 x 3/8" PPH Zinc
8
108755-01 Pilot Bracket
1
9
104506-5 Tube Burner Orifice (Natural Gas)
1
104506-0 Tube Burner Orifice (Propane/LP Gas)
1
10
1458
Brass Elbow Fitting
1
11
14554
Tubing Assembly
1
1
14500
Brass Fitting
1
13
14389
Millivot Valve (Natural Gas)
1
14390
Millivolt Valve (Propane/LP)
1
14
1453
Flexible Gas Line
1
15
11107
Screw #10-3 x 1/4" PPH Zinc
4
16 6808
Valve Bracket
1
17
687
Switch Bracket
1
18
1461
Piezo Ignitor
1
19
109144-0 Air Baffle (Natural Gas Only)
0
108761-0 Grate Assembly
1
1
108346-01 Grate Base
1
1149
Pin
