www.desatech.com 111906-01F 31
PARTS LIST
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts
on page 28 of this manual.
v42NSB(1)
v42PSB(1) vv42NSB(1)
vv42PSB(1)
CHDv42NR-B
v42NHB(1)
v42PHB(1) vv42NHB(1)
vv42PHB(1) DESCRIPtION
qtY.
11199-0 11199-01 11130-0 11130-01 Left Refractory Brick Panel 1
11197-0 11197-01 111300-0 111300-01 Rear Refractory Brick Panel 1
11198-0 11198-01 111301-0 111301-01 Right Refractory Brick Panel 1
kEY
NO. v42N-A
v42PA
vv42NSB(1)
vv42NHB(1)
vv42PSB(1)
vv42PHB(1) CHDv42NR-B DESCRIPtION
qtY.
1 ** ** ** Firebox Assembly 1
** ** ** Face Weldment 1
3 10838-01 10838-01 10838-01 Door Assembly (V and CHDV Models Only) 1
10838-0 10838-0 — Door Assembly (VV Models Only) 1
4 108331-01 108331-01 108331-01 Top Louver Assembly 1
5 108331-0 108331-0 108331-0 Bottom Louver Assembly 1
6 ** ** ** Fireplace Top 1
7 ** ** ** Fireplace Top Insulation 1
8 ** ** ** Fireplace Surround 1
9 10908-0 10908-0 10908-0 Heat Shield 1
10 108778-01 108778-01 108778-01 Log Set
10-1 109396-01 109396-01 109396-01 Front Log (Log 1) 1
10- 109397-01 109397-01 109397-01 Rear Log (Log ) 1
10-3 109398-01 109398-01 109398-01 Crossover Log (Log 3) 1
10-4 109399-01 109399-01 109399-01 Top Center Log (Log 4) 1
10-5 109400-01 109400-01 109400-01 Top Left Log (Log 5) 1
10-6 109401-01 109401-01 109401-01 Top Right Log (Log 6) 1
10-7 10940-01 10940-01 10940-01 Base Log (Log 7) 1
11 — see below see below Left Refractory Brick Panel 1
1 — see below see below Rear Refractory Brick Panel 1
13 — see below see below Right Refractory Brick Panel 1
14 108374-01 108374-01 108374-01 Burner Base Gasket 1
15 108455-01 108455-01 108455-01 Screen Rod 1
16 108740-01 108740-01 108740-01 Screen
17 11418 11418 114118 Push-On Nut
18 1413 1413 1413 Strain Relief 1
19 1171 1171 1171 Gas Knock-Out Cover
0 4353 4353 4353 Handy Box Assembly 1
1 4460 4460 4460 Gas Conduit Assembly 1
10839-01 10839-01 10839-01 Burner Assembly (Natural Gas) (See pages 3 and 33) 1
108639-0 108639-0 108639-0 Burner Assembly (Propane/LP Gas)
PARTS AVAILAbLE - NOT SHOWN
5487 5487 5487 Lava Rock/Bag Assembly 1
753 753 753 Notice Label 1
5540 5540 5540 Vent Label 1
— — BKT Blower Kit 1
— — PCDM-4V Conversion Kit 1
** Not a field replaceable part.
