LBC-HDBT User’s Manual

Link Bridge

TM

HDbaseT HDMI Transmission System

Broadata Technical Support, [email protected]

5

1.0 PRODUCT DESCRIPTION

The LBC-HBT-Tx/Rx with HDMI video and RS-232 over Single CAT5e/6
transmitter and receiver set can send uncompressed audio/video over a
single run of CAT5e/6 cable up to 100 m with PoH (Power over HDBT)
feature and the added benefit of control through the built-in RS-232 and
IR ports and a bi-directional LAN connection.

Features

• HDMI 1.4 with 3D, 4k×2k support, HDCP & DVI Compliant
• Supports CEC bypass

• Simultaneous transmission of uncompressed data over a

single 100m/ 328 ft CAT5e/6 cable

• Uncompressed video 1080p, 60 Hz, 36-bit

• Audio support up to 7.1CH & Dolby TrueHD, DTS-HD

• 5Play™ convergence: HDMI, LAN, Bidirectionlal PoH &

Control (IR & RS-232)

• Installation Friendly

Package Contents

• 1×HDMI to CAT5e/6 (with LAN/IR/RS-232/Bidirectionlal PoH)

Transmitter

• 1×CAT5e/6 to HDMI (with LAN/IR/RS-232/Bidirectionlal PoH)

Reciever

• 1×IR Blaster

• 1×IR Receiver

• 1×24 V/1.25 A DC Power Adaptor

• Operation Manual
