BECKHOFF M2510 User Manual
Page 9
M2510 Analog Input
Beckhoff II/O Lightbus System
Date: 20.08.93
Version : 2.0
Page 9 of 11
e) bipolar
+/-1 Volt
- connect input with ground
- read channel by II/O Lightbus test program or other II/O-Lightbus software
(continuously to provide constant transformation)
- adjust by using potentiometer "Offset bipolar" the read in value to "800h"
- connect and adjust precisely -1V to the input
and then adjust by using potentiometer"GAIN" to the value "000h
Spannungsversorgung
There is a two-pin terminal (X10 Pin1+2) for the supply voltage with connections for control
logic (+).
