Beckhoff New Automation Technology CB3053 page 37
5 BIOS Settings
5.1 Remarks for Setup Use
In a setup page, standard values for its setup entries can be loaded. Fail-safe defaults are loaded with F6
and optimized defaults are loaded with F7. These standard values are independent of the fact that a
board has successfully booted with a setup setting before.
This is different if these defaults are called from the Top Menu. Once a setup setting was saved, which
subsequently leads to a successful boot process, those values are loaded as default for all setup items
afterwards.
See also the chapters “Load Fail-Safe Defaults" (5.10) and “Load Optimized Defaults” (5.11).
N OTE
BIOS features and setup options are subject to change without notice. The settings displayed in the
screenshots on the following pages are meant to be examples only. They do not represent the
recommended settings or the default settings. Determination of the appropriate settings is dependent
upon the particular application scenario in which the board is used.
5.2 Top Level Menu
Phoenix – AwardBIOS CMOS Setup Utility
► Standard CMOS Features ► PC Health Status
► Advanced BIOS Features Load Fail-Safe Defaults
► Advanced Chipset Features Load Optimized Defaults
► Integrated Peripherals Set Password
► Power Management Setup Save & Exit Setup
► PnP/PCI Configurations Exit Without Saving
Esc : Quit ↑ ↓ → ← : Select Item
F10 : Save & Exit Setup
"brief description of selected item"
The sign „ ►“ in front of an item means that there is a sub menu.
The „x“ sign in front of an item means, that the item is disabled but can be enabled by changing or
selecting some other item (usually somewhere above the disabled item on the same screen).
Use the arrow buttons to navigate from one item to another. For selecting an item press Enter which will
open either a sub menu or a dialog screen.
