PAGE 14
FASTENER JAM INSIDE MAGAZINE :
1. Disconnect tool from air hose.
2. NF2502X4, NB1252X4, NB2002X4,
NBSNC2X4
Release the magazine latch to open the
magazine.
Feeder
Magazine
Latch
SNC1002x4
Pull feeder shoe back into "locked" position.
3. Remove jammed fasteners.
4. Reload fasteners into magazine. Refer to
Loading the Tool section in this manual.
