Page 21
21
PARTS
ITEM PART NO.
QTY.
DESCRIPTION
ITEM PART NO.
QTY.
DESCRIPTION
539 101977
1..
....1 .... TRACTION SPRING
539 976952
2..
....1 .... SCREW 10-24 x .625 RD
539 104411
3..
....1
.... KNOB
W/STUD
539 104763
4..
....1 .... RETAINER
5
/
16
“U” TYPE
539 105785
5..
....1 .... DECAL, WARNING
539 106741
6..
....1 .... DECAL, SEVERING
539 108084
7..
....1 .... WASHER,
3
/
16
x ¾ x 16 GA
539 108088
8..
....1 .... LATCH, HOOD
539 108089
9..
....1 .... PLATED, WELD NUT
539 108120
10..
....2 .... NUT ¼-20 HEX NYLOC
539 990717
11..
....5 .... NUT
5
/
16
-18 HEX NYLOC
539 108735
12..
....2 .... NUT ¼-20 HEX FLANGE
539 109552
13..
....2 .... WASH
3
/
16
LOCK
539 110321
14..
....2
.... BOLT,
HEX
3
/
8
-24 x 1¼ GR 8
539 110323
15..
....2
.... WASHER,
HARDENED
539 113683
16..
....1
.... V-IDLER
539 115667
17..
....1
.... KEY,
3
/
16
x ½
539 125229
18..
....1 .... KEY,
3
/
16
x 1½
539 130292
19..
....1 .... IMPELLER
539 130293
20..
....1 .... COVER, BELT
539 130295
21..
....1 .... HUB, BEARING
539 130296
22..
....2 .... BEARING
539 130301
23..
....2 .... BUSHING
539 130309
24..
....1 .... COVER, OUTER PULLEY
539 130313
25..
....6 .... NUT,
5
/
16
-18 TEE
539 130314
26..
.. 11 .... NUT, ¼-20 TEE
539 130315
27..
....6 .... HCS
5
/
16
-18 x ½ GR 5
539 130316
28..
....1 .... SHAFT, IMPELLER
539 130317
29..
....1 .... PIN
539 130323
30..
....1 .... SPACER
539 130324
31..
....1 .... PULLEY
539 130335
32..
....1 .... MOUNT, IDLER, UPPER
539 130336
33..
....1 .... MOUNT, IDLER, LOWER
539 130337
34..
....1 .... ARM, IDLER
539 130338
35..
....1 .... ARM, TENSION
539 132050
36..
....1 .... BRKT, MT, FRONT, 44" DECK
539 132057 ...1 .... BRKT, MT, FRONT, 50" DECK
539 132064 ...1 .... BRKT, MT, FRONT, 60" DECK
539 132052
37..
....1 .... BRKT, MT, REAR, 44" DECK
539 132059 ...1 .... BRKT, MT, REAR, 50" DECK
539 132066 ...1 .... BRKT, MT, REAR, 60" DECK
539 130341
38..
....1 .... PLATE, OUTER
539 130346
39..
....1 .... KEEPER
539 200282
40..
....3 .... NUT,
3
/
8
-16 HEX JAM NYLOC
539 919078
41..
....1 .... IDLER PULLEY
539 976949
42..
....1 .... HCS
3
/
8
-16 x 1¾ GR 5
539 976988
43..
....1 .... HAIRPIN COTTER
539 990055
44..
..13 .... WASHER, ¼ FLAT SAE
539 990302
45..
....8 .... SCREW, ¼ x
3
/
8
THRD FRM
539 108461
46..
....3 .... HCS ¼-20 x ½ GR 5
539 990118
47..
....2
.... WASHER,
3
/
8
SPLT LOCK
539 990122
48..
....2 .... WASHER,
3
/
8
SAE FLT
539 990209
49..
....1 .... HCS
5
/
16
-18 x 1 GR 5
539 990316
50..
....4 .... RHSNB
5
/
16
-18 x ¾ GR 5
539 990643
51..
....2 .... HCS ¼-20 x
7
/
8
GR 5
539 990655
52..
....1 .... HCS
3
/
8
-16 x 1½ GR 5
539 990692
53..
....1 .... WASHER,
5
/
16
STD FLT
539 130349
54..
....1 .... DECAL, BELT ROUTING
539 131085
55..
....1 .... KEEPER, BELT, OUTER
539 131087
56..
....2 .... KEEPER, BELT, REAR
539 132122
57..
....1 .... PLATE, BACKING
539 132124
58..
....1 .... PLATE, BACKING
539 910935
59..
....1 .... WASHER
539 990645
60..
....1 .... RHSB,
3
/
8
-16 x 1
