- 17 - For more information, visit www.desatech.com
ILLUSTRATED PARTS LIST
ITEM DESCRIPTION QTY.
CD32M CD36M CD42M
1 108878-01 108008-01 108326-01 FIREBOX ASSEMBLY 1
2 108874-01 108009-01 108327-01 FACE WELDMENT 1
3 108892-01 108010-01 108328-01 DOOR ASSEMBLY 1
4 108903-01 108011-01 108331-01 PANEL ASSEMBLY LOUVER, FACE TOP 1
5 108903-02 108011-02 108331-03 PANEL ASSEMBLY LOUVER, FACE BOTTOM 1
6 108895-01 108015-01 108333-01 TOP, FIREPLACE 1
7 109096-01 108016-01 108336-01 INSULATION, FIREPLACE TOP 1
8 108896-01 108017-01 108334-01 SURROUND, FIREPLACE 1
9 108885-01 108074-01 108329-05 BURNER ASSEMBLY 1
10 108890-01 108076-01 108374-01 GASKET, BURNER BASE 1
**11 108897-01 108080-01 108351-01 REFRACTORY, REAR 1
**12 - 108081-01 108352-01 REFRACTORY, TOP 1
**13 108901-01 108082-01 108353-01 REFRACTORY, RIGHT 1
**14 108901-02 108083-01 108354-01 REFRACTORY, LEFT 1
15 11418 11418 11418 NUT, PUSH-ON 2
16 108440-01 12105 107840-01 SCREEN 2
17 108455-02 13113 108455-01 ROD, SCREEN 1
18 110037-01 110037-01 110037-01 ELECTRICAL DUCT ASSEMBLY 1
19 21171 21171 21171 COVER, GAS KNOCK-OUT 2
20 24460 24460 24460 CONDUIT ASSEMBLY, GAS 1
21 109082-03 109082-01 109082-02 HEAT SHIELD 1
22 27253 27253 27253 LABEL, NOTICE 1
*23 109222-01 109006-01 108778-01 LOG SET 1
24 11102 11102 11102 SCREW #8-32 x 3/8 PPH ZINC 2
25 11105 11105 11105 SCREW #10 x 1/2 ZINC 9
26 11179 11179 11179 SCREW #10-24 x 1/4 ZINC 4
27 11237 11237 11237 SCREW, TRILAB M4 x 8MM 1
28 14389 14389 14389 VALVE HI-LO SIT (NAT) 1
29 14492 14492 14492 IGNITOR, PIEZO 1
30 14500 14500 14500 FITTING, BRASS 2
31 14253 14253 14253 CONNECTOR, FLEXIBLE 1
32 14511 14511 14511 BRACKET, IGNITOR (SIT) 1
33 14528 14528 14528 FITTING, BRASS ELBOW 1
34 104506-25 104506-23 104506-25 ORIFICE 1
35 104509-02 14576 14544 TUBING ASSEMBLY, ALUMINUM 1
36 26808 26808 26808 BRACKET, VALVE 1
37 26827 26827 26827 BRACKET, SWITCH 1
38 108886-01 108077-01 108346-01 BASE, GRATE 1
39 108891-01 104504-03 108376-01 BURNER 1
40 108084-02 108084-02 108084-02 PILOT ASSEMBLY (NG) 1
41 108889-01 108075-01 108373-01 BURNER BASE ASSEMBLY 1
42 109699-01 - - FACE EXTENSION, RIGHT 1
43 109699-02 - - FACE EXTENSION, LEFT 1
44 109700-01 - - FACE EXTENSION, TOP 1
45 - - 108330-01 BURNER PAN ASSEMBLY 1
46 - - 104506-24 ORIFICE 1
*47 25487 25487 25487 LAVA ROCK/BAG ASSEMBLY 1
***48 110251-01 110251-01 110251-01 MICRO SWITCH ASSEMBLY 1
* ITEMS NOT SHOWN **OPTIONAL ITEMS *** FOR MODELS CD32M-2 & CD36M-2 ONLY
PART #
