Page 5
SPECIFICATIONS
Chassis: 11 GA - rectangular tube.
Body: Two piece - made of DR acrylic reinforced with fiberglass, color fast, scratch
and impact resistant. Front body contains access panels for battery service
and engine to mower deck belt removal. Rear body tilts up to allow service on
the entire drive system.
Seat: Economically designed for operator comfort by use of high density closed cell
foam, contoured back rest and arm rests. Seat is adjustable fore and aft.
Mower Deck: 12 GA stamped steel construction, (3) blades, 50" cut width, cut height 1"
to 4" via 7 position lift handle. Self cleaning design, smoothly curved
front, aides discharge of grass.
Blade Drive: Warner electric clutch.
Drive System: (2) Sundstrand BDU - 10 L hydrostatic transmissions driven by a
permanently lubricated peerless gear box.
Engine: 18 HP Kohler twin cylinder with cast iron cylinder, pressure lubrication and
mechanical fuel pump.
Starting System: Electric by key switch operation with safety interlocks on
parking brake and blade drive clutch.
Tires: Front 11 x 4.10 x 5 smooth tread. Rear 20 x 10 x 8 turf savers.
Capacities: Fuel - 4.8 gallons total (dual tanks) with fuel gauges.
Hydrostat oil tank - 3 quart with inline 10 micron filter.
Hydrostat oil recommendation - name brand SAE (10-W-30) motor oil.
Dimensions: Width - 60" Height -
45" Length - 72"
Weight - 665 lbs.
NOTE: Additional information provided in service instruction under the
individual component.
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE........................
