ELECTRICAL SYSTEM:
SITUATION
Starter will not
turn engine over
Starter will not
turn engine over
Battery discharge
Battery discharge
Battery discharge
Electric clutch will
not engage mower deck
blades
Head lights do not
operate
CAUSE Blown
fuse
Dead battery
Poor connections on
battery
Battery water low
Wrong battery installed in
mower
Engine electrical system
not functioning correctly
Engine being operated at
too low an RPM
Low battery condition
Poor connections on
clutch switch
Broken wiring
Poor connection on lights
Broken wiring
Bad bulb
REMEDY
Inspect and replace fuse
If fuse continues to burn
consult your dealer for
repair
Charge battery
Tighten or renlace as
required
Have electrical system
checked by your dealer
Increase engine RPM
Consult your dealer for
information
Repair or replace as
required
Consult your dealer for
repair
Repair or replace as
required
Note:
Electrical system failures are generally simple in nature, always check the
obvious first and then move onto the more complicated parts used. Poor battery
service, loose connections, corrosion, frayed or broken wiring, are more likely
than component failure.
Page 24
TROUBLE SHOOTING
