Page 13
OPERATION INSTRUCTIONS (continued)
THROTTLE CONTROL LEVER:
Controls engine speed. (Engine should be operated at full throttle when use.d in a
mowing application, this will insure adequate cooling of the engine as well as
maintaining mower deck blade speed) Located on control panel on operators right.
MOWER DECK CUT HEIGHT LIFT LEVER:
Controls the cutting height of the mower deck. Seven positions of adjustment in which
the very top, or highest notch, is used for transporting the mower in a non-mowing
situation. Located in front of operator on the right side of mower.
BLADE DRIVE:
To engage the mower deck cutter blades, lift switch up lightly and push
forward. To disengage blades, pull switch backward. Switch is clearly
marked "on and off".
LIGHT SWITCH:
The headlights are activated by pushing the switch forward. Failure to turn off
the lights, once the engine is stopped, will result in rapid discharge of the
battery.
FUSE BLOCK:
Protection of the electrical system is by (1) 15 AMP fuse. To remove the fuse for
inspection, just simply lift upon fuse block lid. If fuse burns quickly, please
consult your dealer for inspection and repair. Never attempt to bypass the fuse by
any method.
