Page 4
Technical Note
ReFlex Power™ Mating Connectors for FPDC Module
Document No. W380274-01 Rev E
• 1/23/2009
©2008 AMETEK Programmable Power, Inc. • All rights reserved. • AMETEK is a trademark of AMETEK, Inc.
9250 Brown Deer Road, San Diego CA 92121 • Tel: 858-450-0085 • Fax: 858-458-0267 • email:
• Web:
www.programmablepower.com
4 of 4
PIN Signal
Description
14
+5V S RTN
+5V Sense Return
15
-5V S RTN
-5V Sense Return
16
+15V S RTN
+15V Sense Return
17
-15V S RTN
-15V Sense Return
A1
+5V
+5V Positive Output derived after disconnect relay
A2
+5V RTN
+5V Return Output
A3
-5V
-5V Positive Output derived after disconnect relay
A4
-5V RTN
-5V Return
DC OUTPUT CONNECTOR ACCESSORIES
•
AMETEK P/N 5380449-01, FPDC Module, 9ft. Unterminated DC Output Cable Assembly.
•
AMETEK P/N 5380449-03, FPDC Module, Right Angle, 9ft. Unterminated DC Output Cable Assembly.
