To access this section, first press and hold the “display” button, then concurrently press
“2” button. This can only be done from the front panel. It is recommended that once this
section is entered, that all adjustments be made with the remote at some distance from the
unit, so as not to obstruct light from reaching the sensor. LED #2 will light, and the
display will show two numbers in the range 00-15, one on the left display and one on the
right display. The left number indicates the light level that the sensor is reporting, 0 is
darkest and 15 is brightest. The rightmost number indicates the LED brightness setting
for that light level, 0 is darkest and 15 is brightest. LED#2 will be lit, which indicates
that pressing the “up” or “down” buttons will adjust the LED brightness for the current
light level. Pressing button #1 will turn on LED#1, which indicates that pressing the
“up” or “down” buttons will change to a different light level setting, for which the LED
brightness could then be changed by pressing button #2. Changes to the LED brightness
will only be visible for the current light level.
To exit this section, press the “display” button.
Special note:
Setting all brightness levels to the same value, for all light levels, will result in no change
of display or LED brightness with changes in ambient light level in the room.
Restoration of the factory default settings:
To restore the factory settings for all display settings, first press and hold the “display”
button, then concurrently press “3” button. This can only be done from the front panel.
LEDs 1-5 will light, indicating that the unit has restored the factory settings.
Maintenance
Do not, under any condition, remove the top cover while the AC power cord is connected
to the unit. As the power supply remains charged even with power removed, wait at least
20 minutes after removing the AC power cord before attempting any maintenance.
Under normal conditions, internal access is not required. In the event of a noisy tube or
other maintenance, the top cover may be removed. There are no screws, it is securely
held in place by an interlocking material. To remove the top cover, grasp it at the rear
left edge and pull up firmly. The interlocking material will gradually disengage as the
top cover is “peeled” up.
To reinstall the top cover, align the front edge with the back of the faceplate and
gradually press down, starting at the front and moving toward the back.
