Z8 Encore! XP
®
F042A Series Development Kit
User Manual
UM016608-0608 Z8 Encore! XP
®
F042A Series Development
6
Features
The features of Z8 Encore! XP F042A Series Development Board
include:
• Z8 Encore!
®
MCU (28-pin SOIC)
• 3 LEDs
• RS-232 interface
• IrDA transceiver
• Two pushbuttons, RESET and TEST
• 5 V DC power connector
• On-Chip Debugger interface
• 20 MHz Crystal (Y1)
• Header for ADC input
• Prototyping area
• External interface connectors JP1 and JP2
• 2.7 V to 3.6 V operating voltage with 5 V-tolerant inputs
Z8 Encore! XP F042A Series MCU
The Z8 Encore! XP F042A Series MCU is member of a family of Zilog
®
microcontroller products based on the 8-bit eZ8 TM core CPU. The Flash
in-circuit programming capability allows for faster development time and
program changes in the field. The eZ8 core CPU is upward compatible
with existing Z8
®
instructions. The rich peripheral set of the Z8 Encore!
XP F042A Series makes it suitable for various applications including
motor control, security systems, home appliances, personal electronic
devices, and sensors.
