8
Step 5
Place the ceiling box into the into the ceiling grid fame.
Make certain that the direction of the ceiling box is
correct before continuing.
Step 6
Pull the end of the wire rope through the mounting hole
on the ceiling box and loop it back through the Kwik-Loc
cable outlet. Adjust the tightness of the cable so that it is
not pulling the box up from the ceiling. Once completed,
cut off the excess cable.
Electrical
On the main electrical side of the ceiling box is a junction box which contains the main
power leads for the ceiling box. This junction box makes it very easy to supply main power
(120 volts at 60 Hz 15 amp only) to the ceiling box. The wires are 14 gauge stranded.
Wire color
 Black (Line Hot)
 White (Neutral)
 Green (Building Ground)
