41
Dolby Pro Logic II x (Pro Logic II ) mode
2 Select the STANDARD (Dolby Pro Logic II x) mode.
Light
(Main unit) (Remote control unit)
3
Play a program source with the mark.
• For operating instructions, refer to the manuals of the
respective components.
5, 7 4, 6 1 2
4, 6
5, 7
1
8
5, 7
2
4 Select the surround parameter mode.
1 Select the function to which the component you want to play
is connected.
Example: DVD
(Main unit) (Remote control unit)
Display
(Main unit) (Remote control unit)
To perform this operation from the remote control unit,
check that the mode selector switch is set to “AUDIO”.
Display
5 Select the optimum mode for the source.
(Main unit)
(Remote control unit)
• The Dolby Pro Logic indicator lights.
The Dolby Surround Pro Logic
II x Cinema or Music mode can
be chosen directly by pressing
the CINEMA or MUSIC button
on the remote control unit
during playback in the Dolby
Surround Pro Logic
II x mode.
To play in the PL II x mode, set “S. BACK” at the Speaker Configuration setting to “SMALL” or “LARGE”.
• When the “SURROUND BACK” parameter is set to “ON”. (Set “S. BACK” at system set up to “SMALL”
or “LARGE”.)
(Pro Logic II x
Cinema mode)
(Pro Logic II x
Music mode)
(Pro Logic II x
Game mode)
or or
• When the “SURROUND BACK” parameter is set to “OFF”. (Set “S. BACK” at system set up to
“NONE”.)
(Pro Logic II
Cinema mode)
(Pro Logic II
Music mode)
(Pro Logic II
Game mode)
or or
(Dolby Pro Logic
mode)
ENGLISH
